Generator Network or Inverter Network Exchange Relay CBE DS-SR Camper
0363
59.00
Tax included
delivery in 5-7 days
Security policy (edit with Customer reassurance module)
Delivery policy (edit with Customer reassurance module)
Return policy (edit with Customer reassurance module)
230V 20A exchange relay useful for managing the 220V network on board the camper or caravan or in photovoltaic systems.
With this product you can manage the voltage exchange between the grid and the generator or between the grid and the inverter or inverter generator.
The relay coil is 230V so depending on the priority of the line, you will need to connect the network or the generator/inverter to both the switching contacts and the relay coil.
Two examples of use:
- CAMPER, you can connect the inverter to the normally closed contact, so that when there is no mains voltage, the load (electrical sockets) is connected to the inverter.
The electrical network instead will be connected both to the normally open contact and to the relay coil.
When I connect the camper to the 230V column, the relay switches and the sockets will be powered by the mains. - SOLAR SYSTEM. In this case the inverter will be connected to the coil and the normally open contact, while the electrical grid will be connected to the normally closed contact.
In this way, when the inverter switches off because the batteries are flat, the relay automatically switches to the normally closed contact and will therefore connect the load to the electrical grid.
TECHNICAL INFORMATION
- Model: CBE DS-SR
- Working voltage: 220-230V
0363
1 Item
Data sheet
- CBE
DSSR
Specific References
- EAN13
- 8033087731286
- MPN
- DSSR
